Agilent Cary 3500 UV-Vis System

Agilent Cary 3500 UV-Vis System Specification

Display Type
Integrated touchscreen display

Power Supply
Mains powered, universal input

Heating Capacity
Thermostatted sample compartment with temperature control

Temperature Resistance
Sample compartment temperature range: -5 C to +110 C

Accuracy
Wavelength accuracy 0.1 nm

Shape
Rectangular

Glass Type
Quartz cuvettes compatible

Control Type
Touchscreen and PC Software control

Speed Range
Data acquisition up to 80 data points per second

Features
Expandable configuration, synchronous and independent multi-cell measurements, fast data acquisition, robust and compact design, low maintenance

Type
UV-Vis Spectrophotometer

Dimension (L*W*H)
68 cm x 61 cm x 32 cm

Equipment Type
UV-Visible Spectrophotometer

Equipment Materials
Premium industrial-grade materials; corrosion-resistant metals and polymers

Power
220 W

Voltage
100-240 V AC, 50/60 Hz

Material
Metal chassis with polymer housing

Application
Pharmaceutical, Life Science, Chemical Analysis, QA/QC Labs, Research

Capacity (Ltr)
Not applicable (analytical instrument)

Detector Type
Dual silicon photodiode arrays

Spectral Bandwidth
1.5 nm fixed (optional 0.5, 1.0, 2.0, 5.0 nm available on select configurations)

Sample Holder
4/8 cell changer options, temperature-controlled samples

Weight
~28 kg

Light Source
Xenon flash lamp (long-life, maintenance-free)

Stray Light
<0.00008% at 340 nm

Photometric Range
3.3 to +3.3 Abs

Wavelength Range
190 nm 1100 nm

Communication Interface
USB, LAN, and wireless capability

Software Compatibility
Compatible with Cary UV Workstation Software and OpenLab CDS

Baseline Stability
<0.00015 Abs/hr at 500 nm

Operating Environment
Humidity up to 80% non-condensing, 5C to 45C

Agilent Cary 3500 UV-Vis System Trade Information

Minimum Order Quantity
1 Piece

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East

About Agilent Cary 3500 UV-Vis System

The Agilent Cary 3500 UV-Vis Spectrophotometer is a high-performance, double beam instrument designed for accurate, fast, and flexible UV-Vis measurements. It features an innovative air-cooled Peltier temperature control system for in-cuvette thermal ramping from 5 to 110C without water or tubing, supporting ramp rates up to 40C/min. Equipped with a xenon flash lamp, solid-state temperature probes, and a highly collimated beam, it ensures excellent stability and small-volume accuracy. Integrated with the Cary UV Workstation and optional OpenLab compliance software, it provides a secure, user-friendly interface that supports regulatory standards such as FDA 21 CFR Part 11 and ISO/IEC 17025. Modular configurations such as the Multicell and Flexible versions further tailor the system to specific applications in kinetic studies, protein/DNA melting, and concentration analysis. It is ACT-labeled by My Green Lab for environmental sustainability.

Note: The price mentioned above is for reference only. Do not consider it for purchase. For the actual price and more product details, please contact us at +91 98508 70860, +91 84461 74263.

Key Features

Air-cooled Peltier Temperature Control (5 to 110C)
Xenon Flash Lamp with 10-Year Warranty
Double Beam Optical System
Thermal Ramp Rate Up to 40C/min
Spectral Bandwidth: 0.15.0nm
Wavelength Range: 1901100nm
Photometric Range: 4 Abs
Built-in Calculations & Kinetic Applications
OpenLab Compliance Software Support
ACT Label for Sustainability

List No. R

Disclaimer: UNLESS OTHERWISE INDICATED, THE CONTENT OF THIS WEBSITE IS THE PROPRIETARY PROPERTY OF ITS OWNERS. However, trademarks, service marks and/or logos (called "marks") herein associated with the products listed on this website are the property of their respective owners. If they appear with the listed products, it is only used for the purpose of identification of those products. We do not claim any association with the mark owners, unless otherwise so specified. MEANING OF LIST NUMBER: R - Refurbished, PO - Preowned, U - Used, T - Trading, M - Own Manufactured, AD - Authorized Dealer of Original Equipment Manufacturer.

Precision Meets Durability

Engineered with premium industrial materials and a corrosion-resistant chassis, the Agilent Cary 3500 UV-Vis System delivers reliable, long-lasting performance. Its robust construction ensures consistent operation, even in demanding laboratory environments, making it a durable choice for everyday and advanced analyses.

Versatile Measurement Capabilities

The Cary 3500 accommodates both synchronous and independent multi-cell measurements, with flexible options for 4 or 8-cell changers. Its advanced thermostatted sample compartment supports temperature-controlled experiments between -5 C and +110 C, ensuring accurate data for a variety of applications.

Advanced Connectivity and Control

Benefit from integrated touchscreen control, as well as compatibility with Cary UV Workstation Software and OpenLab CDS. The spectrophotometer offers seamless connectivity via USB, LAN, and wireless options, streamlining data management and integration within modern lab infrastructures.

FAQ's of Agilent Cary 3500 UV-Vis System:

Q: How does the Agilent Cary 3500 UV-Vis System ensure long operational life with minimal maintenance?

A: The Cary 3500 utilizes a long-life, maintenance-free Xenon flash lamp and corrosion-resistant construction, which significantly reduces the need for routine lamp replacements or instrument servicing, ensuring maximum uptime and reliability.

Q: What sample environments and cuvette types are compatible with this instrument?

A: The Cary 3500 is compatible with quartz cuvettes and offers a thermostatted sample compartment capable of controlling temperatures between -5 C and +110 C, supporting a wide variety of analytical requirements, including temperature-sensitive experiments.

Q: When should I use different spectral bandwidth options?

A: Different spectral bandwidths-including 0.5, 1.0, 1.5, 2.0, and 5.0 nm-allow users to optimize resolution versus light throughput based on their experiment. Tighter bandwidths increase spectral resolution for detailed analyses, while broader bandwidths are suitable for rapid, high-throughput testing.

Q: Where can this spectrophotometer be integrated within laboratory settings?

A: The Agilent Cary 3500 is designed for diverse applications across pharmaceutical, life sciences, QA/QC, chemical analysis, and research labs, fitting seamlessly due to its universal connectivity, robust design, and compliance with global electrical standards (100-240 V AC).

Q: What is the data acquisition speed and how does it benefit laboratory processes?

A: The Cary 3500 captures up to 80 data points per second, allowing for rapid and robust spectral analysis. This speed optimizes throughput in high-volume labs, accelerating workflows and enhancing productivity.

Q: How is the instrument controlled and what are the available interfaces?

A: Control is accessible via an integrated touchscreen display or through dedicated PC software (Cary UV Workstation Software and OpenLab CDS). The system supports USB, LAN, and wireless interfaces for effortless data transfer and connectivity.

Q: What are the primary benefits of using the Cary 3500 in a regulated lab environment?

A: Benefits include exceptional wavelength accuracy (0.1 nm), high baseline stability, versatile sample handling, and comprehensive software compatibility-making the Cary 3500 an excellent choice for regulatory compliance, reliable data acquisition, and simplified operation in any laboratory.
